Product Description
The Winterhalter UC-L is the tall undercounter warewasher in the UC range, taking the same 500 x 500 mm rack as the UC-M on a 404 mm clear entry height so it washes taller items without a bigger footprint.
Product Features
- 404 mm clear entry height on a 500 x 500 mm rack - 95 mm more than the UC-M, for taller glassware, jugs and stockpots
- Smart touch display with single-button operation and a language-neutral pictogram interface
- VarioPower adjustable wash pressure, and elliptical quick-release wash fields top and bottom
- Quadruple filtration with a clouding sensor that decides when the tank water needs changing
- Connected Wash digital connectivity fitted as standard
- Rinse water consumption 2 litres per cycle; tank capacity 15.3 litres
- Cycle times 60, 90 and 180 seconds, adjustable
- Noise emission 55 dB(A)
- Supplied with a 15 amp plug and lead, 1 m water and waste hoses, a 500 x 500 mm flat rack and a 500 x 500 mm plate rack
- UC-L Energy: Integrated air-exhaust heat recovery, for lower running costs and a cooler, drier kitchen. The recovery module makes it taller than the standard UC-L - 940 mm against 855 mm - so check the bench clearance.
Product Specifications
- Rack size: 500 x 500 mm
- Clear entry height: 404 mm
- Tank capacity: 15.3 litres
- Rinse water per cycle: 2 litres
- Water connection: 3/4 inch (19 mm), max inlet 60°C, 4 L/min, 1 - 6 bar
- Power (standard): 240 V single phase 50 Hz, 15 amp, 3.2 kW total connected load
- Power (optional): 415 V three phase 50 Hz, 15 or 20 amp, 7.9 kW total connected load
- Material: Stainless steel interior & exterior
- Country of origin: Germany
- UC-L: 600 mm W x 603 mm D x 820-855 mm H, 79 kg packed (69 kg nett)
- UC-L Energy: 600 mm W x 603 mm D x 905-940 mm H, 85 kg packed (75 kg nett)
Downloads
Warranty
Two years parts and labour.
